Tefen Barb Block Fittings

Tefen Barb Block fittings are mechanical push- on compression fittings, made of reinforced polypropylene, that can operate with numerous types of common plastic tubes in the range between 1/4″ – 1/2″.

The fittings sealing system is based on a barb and a tightening nut.

How to make the connection: Insert the nut onto the tube, insert the tube onto the barb and then close and secure the nut tightly on the bar support thread.

Main use: for the connection of plastic tubes on hydraulic and pneumatic systems.

Main Advantages: high chemical resistant, very strong resistant for tube pullout, no rubber seals- long lasting fittings.

What are Tefen fittings used for?
Tefen fittings serve a broad spectrum of international market sectors, such as irrigation, automation, pneumatics, hydraulics, medical devices, and additional industrial applications.

What are the working parameters of Tefen’s fittings?
Working pressure = <14 bar (200 psi) at 20ºC.
Temperature = -20ºC to 120ºC (subject to application).
