Rain Bird ESP-LXME Commercial Modular Controller Automatic Irrigation Controllers

Rain Bird ESP-LXME Commercial Modular Controller Automatic Irrigation Controllers

Name: Durable and easy to clean Rain Bird ESP-LXME Commercial Modular Controller Automatic Irrigation Controllers - Streamduralus.com
SKU: controller-4639110070383
Price: 90.99 USD
Availability: InStock

Original price was: $571.00.Current price is: $90.99.

Model

Clear

SKU: controller-4639110070383 Categories: All Brands, Automatic Irrigation Controllers, Irrigation, Rain Bird Tags: Controller Type_Automatic (AC), Stations_12, Stations_8, Type_Commercial

Best price, safe shopping guarantee
Fast, friendly, always here to help.
Quality You Can Trust
7 days return and exchange

Easily expandable from 8 or 12 stations up to 48 stations with 8- and 12-station modules

The popular Rain Bird® ESP-LX Series commercial controllers have been enhanced to provide additional features and station capacity. The ESP-LXME Enhanced Controller offers flow sensing and management with modular station capacity from 8 to 48 stations. Station modules are available in 8- and 12-station models.

FEATURES:

Hot-swappable modules, no need to power down the controller to add/remove modules
8- or 12-stations base unit expandable to 48 stations with 8- and 12-Station Modules
Flow Smart Module™ factory installed in the 12-station Controller Base (ESP-LXMEF) or as a field upgrade for the 8-station Controller Base (ESP-LXME)
Dynamic station numbering eliminates station numbering gaps
Master valve/pump start circuit
Weather Sensor input with override switch
6 user-selectable languages
Standard 10kV surge protection
Non-Volatile (100-year) program memory
Front panel is removable and programmable under battery power
Compatible with Rain Bird Landscape Irrigation and Maintenance Remote
Plastic, locking, UV resistant, wall-mount case, Optional Metal and Stainless Steel Case & Pedestal

WATER MANAGEMENT FEATURES:

Optional Flow Smart Module™ with Learn Flow utility and flow usage totalizer — standard on ESP-LXMEF
FloWatch™ protection for high and low flow conditions with user defined reactions (requires flow sensor)
FloManager™ manages hydraulic demand, making full use of available water to shorten total watering time
SimulStations™ are programmable to allow up to 5 stations to operate at the same time
Station sequencing by station numbers or station priorities
Water Windows by program plus Manual MV Water Window
Cycle+Soak™ by station
Rain Delay
365-Day Calendar Day Off
Programmable Station Delay by program
Normally Open or Closed Master Valve programmable by station
Weather Sensor programmable by station to prevent or pause watering
Program Seasonal Adjust
Global Monthly Seasonal Adjust

SPECIFICATIONS:

Station timing: 0 min to 12 hrs
Seasonal Adjust: 0% to 300% (16 hrs maximum station run time)
4 independent programs (ABCD)
ABCD programs can overlap
8 start times per program
Program Day Cycles include Custom days of the week, Odd, Odd31, Even, and Cyclical dates
Manual station, program, test program
Input required: 120 VAC ± 10%, 60Hz (International models: 230 VAC ± 10%, 50Hz; Australian models: 240 VAC ± 10%, 50Hz)
Output: 26.5 VAC 1.9A
Power back-up: Lithium coin-cell battery maintains time and date while nonvolatile memory maintains the programming
Multi-valve capacity: Maximum five 24 VAC, 7VA solenoid valves simultaneous operation including the master valve, maximum two solenoid valves per station

Width: 14.32 in (36,4 cm)

Height: 12.69 in (32,2 cm)

Depth: 5.50 in (14,0 cm)

Model	RAINBIRD ESP-LXME 8-STATION COMMERCIAL MODULAR CONTROLLER, RAINBIRD ESP-LXME 12-STATION COMMERCIAL MODULAR CONTROLLER (FLOW SMART MODULE), RAINBIRD ESP-LXME 8-STATION EXPANSION MODULE, RAINBIRD ESP-LXME 12-STATION EXPANSION MODULE, RAINBIRD FLOW SMART MODULE TO SUIT ESP-LXME CONTROLLER
